Methane Emissions in Arctic Cold Season Higher Than Expected

The amount of methane gas escaping from the ground during the long cold period in the Arctic each year and entering Earth’s atmosphere is likely much higher than estimated by current climate change models, concludes a major new study led by San Diego State University.

A team comprising ecologists Walter Oechel (SDSU and Open University) and Donatella Zona (SDSU and the University of Sheffield) and scientists from NASA’s Jet Propulsion Laboratory (JPL), Harvard University, the National Oceanic and Atmospheric Administration, and the University of Montana, found that far more methane is escaping from Arctic tundra during the cold months—when the soil surface is frozen (generally from September through May)—as well as from upland tundra, than prevailing assumptions and climate modelers previously believed. In fact, they found that at least half of the annual methane emissions occur in the cold months, and that drier, upland tundra can be a larger emitter of methane than wet tundra. The finding challenges critical assumptions in current global climate models. The results are published today in the Proceedings of the National Academy of Sciences.

Methane is a potent greenhouse gas that intensifies atmospheric warming and is approximately 25 times more potent per molecule than carbon dioxide over a 100-year period. Methane trapped in the Arctic tundra comes primarily from microbial decomposition of organic matter in soil that thaws seasonally. This methane naturally seeps out of the soil over the course of the year, but scientists worry that climate change could lead to the release of even larger emissions from organic matter that is currently stabilized in a deep, frozen soil layer called permafrost.

Accurate measurements

Over the past several decades, scientists have used specialized instruments to accurately measure methane emissions in the Arctic and incorporated those results into global climate models. However, almost all of these measurements have been obtained during the Arctic’s short summer. The region’s long, brutal cold period, which accounts for between 70 and 80 percent of the year, has been largely “overlooked and ignored,” according to Oechel. Most researchers, he said, figured that because the ground is frozen solid during the cold months, methane emissions practically shut down for the winter.

“Virtually all the climate models assume there’s no or very little emission of methane when the ground is frozen,” said Oechel, co-director of SDSU's Center for Climate and Sustainability Studies. “That assumption is incorrect.”

The water trapped in the soil doesn’t freeze completely even below zero degrees Celsius, he explained. The top layer of the ground, known as the active layer, thaws in the summer and refreezes in the winter, and it experiences a kind of sandwiching effect as it freezes. When temperatures are right around zero degrees Celsius—the so-called “zero curtain”—the top and bottom of the active layer begin to freeze, while the middle remains insulated. Microorganisms in this unfrozen middle layer continue to break down organic matter and emit methane many months into the Arctic’s cold period each year.

Just how much methane is emitted during the Arctic winter? To find out, Oechel and Zona oversaw the upgrading of five sampling towers to allow them to operate continuously year-round above the Arctic Circle in Alaska. The researchers recorded methane emissions from these sites over two summer-fall-winter cycles between June 2013 and January 2015. It was an arduous task requiring highly specialized instruments that had to operate continuously and autonomously through extreme cold for months at a time. They developed a deicing system that eliminated biases in the measurement and that was only activated when needed to maintain operation of the instruments down to minus 40 degrees Celsius.

Zero curtain

After analyzing the data, the research team found that a major portion of methane emissions during the cold season were observed when temperatures hovered near the zero curtain.

“This is extremely relevant for the Arctic ecosystem, as the zero curtain period continues from September until the end of December, lasting as long or longer than the entire summer season,” said Zona, the study’s first author. “These results are opposite of what modelers have been assuming, which is that the majority of the methane emissions occur during the warm summer months while the cold-season methane contribution is nearly zero.”

Surprisingly, the researchers also found that during the cold season, the relative methane emissions were higher at the drier, upland tundra sites than at wetland sites, contradicting yet another longstanding assumption about Arctic methane emissions. Upland tundra was previously assumed to be a negligible contributor of methane, Zona said.

“The freezing of the surface inhibits methane oxidation, resulting in significant net methane emissions during the fall and winter,” she said. “Plants act like chimneys facilitating the methane’s escape through the frozen layer to the atmosphere.”

The highest annual emissions were observed in the upland site in the foothills of the Brooks Range where warm soils and deep active layer resulted in high rates of methane production.

Model adjustment

To complement and verify the on-the-ground study, researchers from the University of Montana used satellite microwave sensor measurements to develop regional maps of surface water cover, including the timing, extent and duration of seasonal flooding and drying of the region’s wetlands.

And to test whether their site-specific sampling was representative of methane emissions across the Arctic, the researchers compared their results to measurements recorded during flights over the region made by NASA’s Carbon in Arctic Reservoirs Vulnerability Experiment. The data from the SDSU sites were well aligned with the larger-scale aircraft measurements, Zona said.

Oechel and Zona stressed the importance for climate modelers to have good baseline data on methane emissions and to adjust their models to account for Arctic cold-season methane emissions as well as the contributions of non-wetland areas, including upland tundra.

“If you don’t have the mechanisms right, you won’t be able to make predictions into the future based on anticipated climate conditions,” he said.

SDSU; NASA JPL; Harvard University; the University of Montana; the University of Sheffield; the National Research Council (CNR) of Italy; the University of Helsinki; the University of Colorado, Boulder; Atmospheric and Environmental Research, Lexington; the University of Alaska, Fairbanks; Dalhousie University; the National Oceanic and Atmospheric Administration; and Open University in Milton Keynes all contributed to the study.

This research has been funded by the National Science Foundation (NSF), NASA, and Department of Energy (DOE).
